Descripción

• Product Name: Gx Ii Gold 750
• Codigo: Mpx-7503-Afag-2
• Peak Power: 750W
• Form Factor: Atx 12V Ver. 3.0
• Modular: Full Modular
• 80 Plus: 80 Plus Gold
• Pfc: Active Pfc
• Input Voltage: 100-240V
• Input Current: 10 - 5A
• Input Frequency: 50 - 60Hz
• Dimensiones: 160 X 150 X 86Mm
• Fan Size: 120Mm
• Fan Bearing: Hdb
• Fan Speed: 2500 Rpm
• Efficiency: = 90% @ Typical Load
• Erp 2014 Lot 3: Yes
• Operating Temperature: 0 ~ 40?
• Power Good Signal: 100-150 Ms
• Hold Up Time: = 16Ms @80%Load
• Mtbf: 100,000 Hours
• Protections: Opp/ Ovp/ Otp/ Ocp/ Scp/ Uvp/ Surge Inrush Protection
• Regulatory: Ctuvus, Tuv, Ce, Fcc, Bsmi, Ccc, Eac, Rcm, Ukca, Rohs2.0 / Bis, Kc (Based On Regions Request.)
• Conector Atx 24 Pines: X1 = 1X (550Mm)
• Conector Eps 4+4 Pines: X1 = 1X (600Mm)
• Conector Eps 8 Pines: X1 = 1X (600Mm)
• Conector Sata: X6 = 2X (500(S)+120(S)+120(S)+120(P)Mm)
• Conector Peripheral 4 Pines: X2 = 2X (500(S)+120(S)+120(S)+120(P)Mm)
• Conector Pci-E 6+2 Pines: X4 = 2X (500+120Mm)
• Conector 12Vhpwr: X1 = 1X (650Mm)
• Ac Input: 100-240V~ 10 - 5A 50 - 60Hz
